Double-sided negative barpeeling insert, 80 Degree trigon with inscribed circle diameter of 22.225 mm, 9.52 mm thick for 3.5 mm depth of cut,, chip-breaker PM, in grade 6630, a MT-CVD coated functionally graded WC-Co carbide within ISO range P15-P35, for steels.
Product Specifications
| EDP Number | 6752846 |
| Min Cutting Depth (mm) | 0.8 mm |
| Max Depth of Cut (mm) | 3.5 mm |
| Max Depth of cut (Inch) | 0.138" |
| Coating Property | 1 |
| Insert Included Angle | 75 |
| Fixing Hole Diameter (mm) | 7.94 mm |
| Fixing Hole Diameter (Inch) | 0.313" |
| Cutting Edge Length (mm) | 15 mm |
| Cutting Edge Length (Inch) | 0.591" |
| Inscribed Circle Diameter (mm) | 22.225 mm |
| Inscribed Circle Diameter (Inch) | 0.875" |
| Insert Thickness (mm) | 9.52 mm |
| Insert Thickness (Inch) | 0.375" |
| Major Cutting Edge Angle | 15 |
| Wiper Edge Length (mm) | 13 mm |
| Wiper edge Length (Inch) | 0.472" |
| Coating Process | MT-CVD |
| Coating | 6630 |
| Surface Color | Gold |
| Min Depth of Cut (mm) | 0.5 mm |
| Min Depth of Cut (Inch) | 0.02" |
| Chipbreaker Manufacturer's Designation | PM |
| Country of origin | Czech Republic |
