Product Specifications
| Weight | 89 lbs |
| Brand | Pratt Burnerd America |
| Chuck Size | 10" |
| Thru-Hole Diameter (mm) | 78mm |
| Thru-Hole Diameter (Inch) | 3.07" |
| Mount | A-8 |
| Maximum Gripping Capacity (Inch) | 10.00" |
| Minimum Gripping Capacity (Inch) | 1.220" |
| Maximum Gripping Force (lb/f) | 28,485 lb/f |
| Maximum Draw Bar Pull (lb/f) | 11,025 lb/f |
| Jaw Stroke Diameter (Inch) | 0.346" |
| Piston Stroke Length (inch) | 0.748" |
| Maximum RPM | 4200 RPM |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Pratt Burnerd America
Chuck Diameter (Inch):
10"
Number of Jaws:
3
Mount:
A-8
Through-Hole Diameter (Decimal Inch):
3.0700"
Through-Hole Diameter (mm):
78mm
Chuck Actuation Style:
Drawbar
Operation Type:
Hydraulic
Ships:
From Partner Facility
interval quantity:
1
