Imperial Carbide Centers cover the requirements for a wide range of workpiece center holes. They reduce costs by eliminating the need for special dead centers. Knockout ends are hardened on carbide tipped dead centers.
<| # MFG | 69505 |
| Taper | 5 Morse |
| Accuracy | ± 0.00005 |
| Gage Line to Point (Inch) | 3.313" |
| Point Diameter (Inch) | 1.750" |
| Center Style | Half Carbide Center |
| Carbide Tip Diameter (Inch) | 1.250" |
| Height Above Center Line (Inch) | 0.250" |
| Point Style | Large Carbide Point |
| Series | Imperial Dead Centers |
