Royal 42342 | Accu-Length 3.25" Diameter x 7.25" OAL Low- Profile A2-8 16C CNC Collet Chuck

$7,260.00 $6,534.00
(You save $726.00)
SKU:
55003546
UPC:
Weight:
65.50 LBS
Shipping:
Free Shipping

Royal Low-Profile Accu-Length Cnc Collet Chucks

  • Simple Design -
  • Spindle Bearing Protection -
  • Bolt & Go - Exclusive Bolt & Go mounting feature is standard on all Royal Low-Profile Collet Chuck models. Bolt & Go enables chucks to be mounted very quickly and ensures maximum accuracy and rigidity. Click here for additional information
  • Completely Sealed - Lubricated for life, these chucks incorporate multiple O-ring seals to keep contaminants out and prevent chip pack-up on bore-thru applications
  • Dead-Length Operation - Royal Quick-Grip Accu-Length CNC Collet Chucks incorporate dead-length operation to eliminate part pullback. With this design, the collet is held stationary in the chuck body and a tapered sleeve pushes forward to compress it, resulting in precise z-axis workpiece positioning
  • Specials - If you have a special application that goes beyond the scope of standard line.
  • Outstanding Rigidity - All Royal Accu-Length Collet Chucks have been optimized for maximum rigidity, and all components hardened for strength and durability
  • Low-Profile - All external dimensions have been optimized to provide maximum tool clearance
  • High Accuracy - All Royal Accu-Length CNC Collet Chucks guaranteed to run within 0.0002"" TIR
  • Wide Range - Royal manufactures a wide range of Accu-Length Collet Chucks to fit all popular spindle noses and collet styles
  • Easy Installation - All Royal Low-Profile Accu-Length Collet Chucks include a collet wrench, mounting hardware, mounting wrenches, and a custom-machined drawtube connector for hassle-free installation.AdvantagesThese chucks utilize spring-type collets and therefore do not provide the parallel grip functionality or wide gripping range of Quick-Grip models
  • Dead-length operation – sleeve pushes forward to compress the collet, providing precise z-axis part positioning
  • Low-profile nose offers outstanding tool clearance.

Product Specifications
Spindle Type A2-8
Collet Chuck Weight (lbs) 51
Collet Type 16C
Low-Profile Capacity (Inch) 1 5/8""
(A) Overall Length 7.25
(B) Nose Diameter (Inch) 3.25"
(C) Nose Length 1.03
(D) Body Diameter 3.67
(E) Flange Diameter 9.45
Max Drawbar Force (lbs) 5,400
Max Clamping Force (lbs) 18,300
Max RPM 4,500
