Seco Tools 03272993 | 0.708" Inscribed Circle Diameter x 0.020" Radius x 0.191" Thickness 8 Cutting Edge Carbide Octomill Insert

$34.60 $28.40
(You save $6.20)
Brand:
Seco Tools
Material:
Carbide
Inscribed Circle (Decimal Inch):
0.7080"
Inscribed Circle (mm):
17.97mm
Thickness (Decimal Inch):
0.1910"
Thickness (mm):
4.86mm
interval quantity:
10
SKU:
23287193
UPC:
Weight:
0.03 LBS
Minimum Purchase:
10 units
Shipping:
Free Shipping
Seco Tools 03272993 | 0.708" Inscribed Circle Diameter x 0.020" Radius x 0.191" Thickness 8 Cutting Edge Carbide Octomill Insert

Product Specifications
Manufacturer Part Number03272993
Inscribed Circle Diameter (Decimal Inch)0.708"
Inscribed Circle Diameter (mm)17.97mm
Wiper Edge Length (Decimal Inch)0.043"
Wiper Edge Length (mm)1.10mm
Cutting Edge Effective Length (Decimal Inch)0.280"
Cutting Edge Effective Length (mm)7.10mm
Corner Radius (Decimal Inch)0.020"
Corner Radius (mm)0.50mm
Insert Thickness (Decimal Inch)0.191"
Insert Thickness (mm)4.86mm
Clearance Angle Major (Degree)26 Degree
Cutting Edge Count8
Cutting Geometry Type TechnicalM15
Pocket Seat Code of The CutterOF..0704
Insert Size And ShapeOFMT0704
Insert HandNeutral
MaterialCarbide
Product TypeOctomill Insert

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov
