Seco Tools 03290941 | ZOMX160716TR-M12 0.063" Corner Radius x 0.286" Thickness 4 Cutting Edge Carbide Milling Insert

$38.30 $31.44
(You save $6.86)
Brand:
Seco Tools
Material:
Carbide
Width (Decimal Inch):
0.4236"
Width (mm):
10.76mm
Thickness (Decimal Inch):
0.2858"
Thickness (mm):
7.26mm
interval quantity:
10
SKU:
23288212
UPC:
Weight:
0.03 LBS
Minimum Purchase:
10 units
Shipping:
Free Shipping
Seco Tools 03290941 | ZOMX160716TR-M12 0.063" Corner Radius x 0.286" Thickness 4 Cutting Edge Carbide Milling Insert

Product Specifications
Manufacturer Part Number03290941
Fixing Hole Diameter (Decimal Inch)0.189"
Fixing Hole Diameter (mm)4.80mm
Cutting Edge Effective Length (Decimal Inch)0.610"
Cutting Edge Effective Length (mm)15.50mm
Wiper Edge Length (Decimal Inch)0.047"
Wiper Edge Length (mm)1.20mm
Corner Radius (Decimal Inch)0.063"
Corner Radius (mm)1.60mm
Insert Thickness (Decimal Inch)0.286"
Insert Thickness (mm)7.26mm
Insert Thickness 1 (Decimal Inch)0.197"
Insert Thickness 1 (mm)5.00mm
Cutting Edge Count4
Insert Rake Angle (Degree)29 Degree
Insert HandRight Hand
Cutting Geometry TypeM
Cutting Geometry Type TechnicalM12
Pocket Seat Code of The CutterZO.X1607
Insert Size And ShapeZOMX1607
MaterialCarbide
Product TypeMilling Insert
