Seco Tools 10260302 | OOET0605ZZER-M10 0.622" Inscribed Circle Diameter x 0.024" Radius x 0.219" Insert Thickness 8 Cutting Edge PVD Coated Carbide MP2050 Grade OOET Milling Insert

$44.60 $34.34
(You save $10.26)
Brand:
Seco Tools
Finish/Coating:
PVD
SKU:
23346679
UPC:
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
Seco Tools 10260302 | OOET0605ZZER-M10 0.622" Inscribed Circle Diameter x 0.024" Radius x 0.219" Insert Thickness 8 Cutting Edge PVD Coated Carbide MP2050 Grade OOET Milling Insert

Product Specifications
Manufacturer Part Number10260302
Clearance Angle Major (Degree)18.00 Degree
Wiper Edge Length (Decimal Inch)0.059"
Cutting edge count8
Cutting Geometry Type TechnicalM10
Insert size and shapeOOET0605
Grade TypeCarbide PVD
Inscribed Circle Diameter (Decimal Inch)0.622"
Insert HandRight Hand
Cutting Edge Effective Length (Decimal Inch)0.177"
Corner Radius (Decimal Inch)0.024"
Insert Thickness (Decimal Inch)0.219"
Product SeriesOOET
Product TypeMilling Insert
