Seco Tools 10260303 | OOMT060510EN-M10 0.621" Inscribed Circle Diameter x 0.039" Radius x 0.219" Insert Thickness 8 Cutting Edge PVD Coated Carbide MS2050 Grade OOMT Milling Insert

$32.40 $26.59
(You save $5.81)
Brand:
Seco Tools
Finish/Coating:
PVD
SKU:
23346680
UPC:
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
Seco Tools 10260303 | OOMT060510EN-M10 0.621" Inscribed Circle Diameter x 0.039" Radius x 0.219" Insert Thickness 8 Cutting Edge PVD Coated Carbide MS2050 Grade OOMT Milling Insert

Product Specifications
Manufacturer Part Number10260303
Clearance Angle Major (Degree)18.00 Degree
Cutting edge count8
Cutting Geometry Type TechnicalM10
Insert size and shapeOOMT0605
Grade TypeCarbide PVD
Inscribed Circle Diameter (Decimal Inch)0.621"
Insert HandNeutral
Cutting Edge Effective Length (Decimal Inch)0.224"
Corner Radius (Decimal Inch)0.039"
Insert Thickness (Decimal Inch)0.219"
Product SeriesOOMT
Product TypeMilling Insert
