Seco Tools 10312647 | SNMU120410TN-MD13 0.472" Circle Diameter x 0.189" Thickness x 0.039" Radius 8 Edge Count CVD Coated MK1501 Grade Carbide Milling Insert

$34.80 $26.56
(You save $8.24)
Brand:
Seco Tools
Thickness (Decimal Inch):
0.1890"
Finish/Coating:
CVD
Material:
Carbide
interval quantity:
1
SKU:
23462607
UPC:
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
Seco Tools 10312647 | SNMU120410TN-MD13 0.472" Circle Diameter x 0.189" Thickness x 0.039" Radius 8 Edge Count CVD Coated MK1501 Grade Carbide Milling Insert

Product Specifications
Manufacturer Part Number10312647
Wiper Edge Length (Decimal Inch)0.039"
Inscribed Circle Diameter (Decimal Inch)0.472"
Cutting Edge Length (Decimal Inch)0.472"
Cutting Edge Effective Length (Decimal Inch)0.386"
Corner Radius (Decimal Inch)0.039"
Insert Thickness (Decimal Inch)0.189"
Insert Size and ShapeSNMU1204
Cutting Edge Count8
Cutting Geometry Type TechnicalMD13
GradeMK1501
Grade typeCarbide CVD
Insert HandNeutral
CoatingCVD
MaterialCarbide
Product TypeMilling Insert
