SGS 37992 | 0.125" Diameter x 0.125" Shank x 0.250" LOC x 2.000" OAL x 0.010" Radius 5 Flute TM (Ti-NAMITE-M) Coated Corner Radius End Mill

$30.15
Brand:
SGS
Overall Length (Inch):
2"
Overall Length (Decimal Inch):
2.0000"
Overall Length (mm):
50.80mm
Length of Cut (Inch):
1/4"
Length of Cut (Decimal Inch):
0.2500"
Length of Cut (mm):
6.35mm
Finish/Coating:
TM (Ti-NAMITE-M)
interval quantity:
1
SKU:
25256193
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
SGS 37992 | 0.125" Diameter x 0.125" Shank x 0.250" LOC x 2.000" OAL x 0.010" Radius 5 Flute TM (Ti-NAMITE-M) Coated Corner Radius End Mill

Related Products

Features:

  • Positive Radial Rake
  • Variable Flute Pattern
  • Open Center Design
  • Long Reach

Product Specifications
Manufacturer Part Number37992
Cutting Diameter (Inch)1/8"
Cutting Diameter (Decimal Inch)0.125"
Cutting Diameter (mm)3.18mm
Shank Diameter (Inch)1/8"
Shank Diameter (Decimal Inch)0.125"
Shank Diameter (mm)3.18mm
Length of Cut (Inch)1/4"
Length of Cut (Decimal Inch)0.250"
Length of Cut (mm)6.35mm
Overall Length (Inch)2"
Overall Length (Decimal Inch)2.000"
Overall Length (mm)50.80mm
Reach (Inch)1/2"
Reach (Decimal Inch)0.500"
Reach (mm)12.70mm
Neck Diameter (Decimal Inch)0.119"
Neck Diameter (mm)3.02mm
Corner Radius (Decimal Inch)0.010"
Corner Radius (mm)0.25mm
Shank Diameter Toleranceh6
Flute TypeSpiral
Number of Flutes5
Center CuttingNo
Chip BreakerNo
High PerformanceYes
CoatingTM (Ti-NAMITE-M)
Product TypeCorner Radius End Mill
