Product Specifications
| Cutting Diameter (mm) | 11.0mm |
| Shank Diameter (mm) | 11.0mm |
| Length of Cut (mm) | 47.0mm |
| Overall Length (mm) | 95.0mm |
| Shank Length (mm) | 49.6mm |
| Cut of Direction | RHC |
| Flute Type | Spiral |
| Cleared Length (mm) | 33 mm |
| Helix Angle | 30 Degree |
| Point Angle | 150 Degree |
| Coating | Uncoated |
| Number of Flutes | 3 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
SGS
Drill Point Angle:
150°
Overall Length (Inch):
3-47/64"
Overall Length (Decimal Inch):
3.7402"
Overall Length (mm):
89mm
Finish/Coating:
UN
Flute Type:
Spiral
Cutting Direction:
RHC
