Features:
- Coolant through design promotes controlled and consistent operating temperatures improving coolant flow to the cut while maintaining strength
- Split point geometry for improved drill penetration and accuracy
- Controlled edge honing for longevity
- Negative corner position strengthens and protects
- Recommended for materials ≤ 60 HRC (≤ 654 BHN)
Product Specifications
| Cutting Diameter (mm) | 12.8mm |
| Shank Diameter (mm) | 14.0mm |
| Length of Cut (mm) | 133mm |
| Overall Length (mm) | 178mm |
| Shank Length (mm) | 45.0mm |
| Cut of Direction | RHC |
| Flute Type | Spiral |
| Cleared Length (mm) | 112 mm |
| Helix Angle | 30 Degree |
| Point Angle | 140 Degree |
| Coating | AlTiN |
| Number of Flutes | 2 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
SGS
Flute Type:
Spiral
Drill Point Angle:
140 Degree
Overall Length (Inch):
4.0157"
Overall Length (Decimal Inch):
3.2280"
Overall Length (mm):
178mm
Cutting Direction:
RHC
Finish/Coating:
TA
interval quantity:
1
