Features
- The rotating spindle is extended right through the tapered shank
- Two specially designed adjustable needle-roller bearings carry all radial loads
- A heavy duty ball thrust bearing takes all axial thrust
- Complete protection of bearings form the ingress of coolant, dirt or swarf is provided by the built-in oil-seal, which also prevents loss of lubricant
Product Specifications
| Manufacturer Part Number | 310125 |
| Shank Type | Taper Shank |
| Taper Size | MT5 |
| Maximum Workpiece Weight (lbs.) | 4400 lbs. |
| Point Diameter (Inch) | 1-3/4" |
| Included Angle (Degree) | 60 Degree |
| Model Number | CSN 243324 |
| Head Diameter (Inch) | 2-3/4" |
| Overall Length (Inch) | 9-1/2" |
| Product Type | Live Center |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Skoda
Diameter (Inch):
1-3/4"
Diameter (Decimal Inch):
1.7500"
Diameter (mm):
44.45mm
interval quantity:
1
