Features
- For clamping of heavy workpieces at lathes
- The rigid structure and seating of the turning part is characterized by long service life
- The model EXTRA is commonly used for work at grinding machines
- Centers with the apex angle of 60 degree for reduction of deformations of the machine (tailstock, bed, headstock) from axial clamping forces
- The live centers are provided with shanks according to DIN 228 and ISO 296 (without clamping thread)
Product Specifications
| Manufacturer Part Number | 310925 |
| Shank Type | Taper Shank |
| Taper Size | MT5 |
| Maximum Workpiece Weight (lbs.) | 5500 lbs. |
| Point Diameter (Decimal Inch) | 3.54" |
| Tip Diameter (Decimal Inch) | 1.65" |
| Included Angle (Degree) | 60 Degree |
| Model Number | CSN 243325 |
| Head Length (Decimal Inch) | 5.6" |
| Overall Length (Decimal Inch) | 9.48" |
| Product Type | Live Center |
