Product Specifications
| EDP Number | 18T5APC |
| Product Code - ANSI | GCMN3015-RN-AC5015S |
| Manufacturer Grade Identification | AC5015S |
| Series | GND |
| Maximum Depth of Cut (Decimal Inch) | 0.7500" |
| Maximum Depth of Cut (mm) | 20.00mm |
| Cutting Width (Decimal Inch) | 0.1181" |
| Cutting Width (mm) | 3.00mm |
| Height (Decimal Inch) | 0.1496" |
| Nose Radius (Decimal Inch) | 0.0591" |
| Nose Radius (mm) | 1.50mm |
| Insert Thickness (Decimal Inch) | 0.1496" |
| Insert Thickness (mm) | 3.80mm |
| Relief Angle | 7 Degree |
| Coating | Absotech |
| Coating Process | PVD |
| Standard Designation of the Grade, Main Application | M, K, S |
| Primary Workpiece Material | M, K, S |
| Secondary Workpiece Material | M, K, S |
| Chip Breaker | RN |
| Insert Hand | N |
| Insert Material | Carbide |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Sumitomo
Insert Style:
GCMN
Insert Size:
3
Material:
Carbide
Length (Inch):
7/8"
Length (Decimal Inch):
0.8820"
Length (mm):
22.40mm
Thickness (Inch):
5/32"
Thickness (Decimal Inch):
0.1500"
Thickness (mm):
3.80mm
Corner Radius (Inch):
1/16"
Corner Radius (Decimal Inch):
0.0590"
Corner Radius (mm):
1.50mm
Manufacturer's Grade:
AC5015S
interval quantity:
5
Ships:
From California in 1-2 Days
