Features:
- 3.5X clamping force of standard hydraulic chucks
- 74% thicker bore walls improve rigidity in heavy material removal applications
- Excellent vibration dampening properties enhances surface finish and extends tool life
Product Specifications
| Taper | CAT40 |
| Nose Diameter (mm) | 49.2mm |
| Body Diameter (mm) | 49.2mm |
| Overall Diameter (mm) | 44.45mm |
| Projection (mm) | 64.5mm |
| Nose Length (mm) | 45.4mm |
| Bore Depth (mm) | 48mm |
| Overall Length (mm) | 132.74mm |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Techniks
Taper Size:
CAT40
Body Diameter (mm):
49.20mm
Nose Diameter (mm):
49.20mm
Overall Length (mm):
132.74mm
Overall Diameter (mm):
44.45mm
Bore Size (mm):
20.00mm
Bore Depth (mm):
48.00mm
interval quantity:
1
