Product Specifications
| # Manufacturer Number | CD32314 |
| Drill Diameter (Decimal Inch) | 0.2813" |
| Flute Length (Decimal Inch) | 1.5000" |
| Flute Length (Inch) | 1-1/2" |
| Overall Length (Decimal Inch) | 2.6875" |
| Overall Length (Inch) | 2-11/16" |
| Point Angle (Degree) | 135 Degree |
| Number of Flutes | 2 |
| Material | High speed steel |
| Coating | Bright Coated |
| Product Type | Screw Machine Length Drill Bit |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Titan USA
Drill Point Angle:
135 Degree
Flute Length (Inch):
1-1/2"
Flute Length (Decimal Inch):
1.5000"""
Flute Length (mm):
38.10mm
Overall Length (Inch):
2-11/16"
Overall Length (Decimal Inch):
2.6875"""
Overall Length (mm):
68.26mm
Material:
High speed steel
Finish/Coating:
Bright Coated
interval quantity:
6
