Features:
- Jobber length for deeper drilling applications
- Optimized for drilling stainless steels, nickel-based alloys, and titanium alloys
- 135 Degree Split Point, Type "J" (diameters<0.0625" are not split)
- AlTiN coating offers increased wear and heat resistance
- M-42 cobalt (identification ring on shank)
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | CD60923 |
| Drill Diameter (Inch) | 0.3860" |
| Shank Diameter (Inch) | 0.3860" |
| Overall Length (Inch) | 5.1250" |
| Flute Length (Inch) | 3.7500" (3-3/4) |
| Point Angle (Degree) | 135 Degree |
| Coating | AlTiN |
| Substrate | Cobalt |
| Number of Flutes | 2 |
| Product Type | Jobber Length Drill Bit |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Titan USA
Drill Bit Size (Inch):
25/64"
Drill Bit Size (Decimal Inch):
0.3860"
Drill Bit Size (mm):
9.80mm
Drill Point Angle:
135 Degree
Overall Length (Inch):
5-1/8"
Overall Length (Decimal Inch):
5.1250"
Overall Length (mm):
130.18mm
Material:
Cobalt
Finish/Coating:
AlTiN
interval quantity:
6
