Offered in stub or regular length styles, this Titan USA solid carbide, fully stocked offering of general purpose end mills features 5 flutes, a corner radius profile, and a 45 Degree helix for increased edge strength.
Features:
- Excellent performance in profiling and finishing applications
- Offered in stub and regular length styles
- 45 Degree helix for faster chip removal and a better finish
- Corner radius for increased edge strength
- 5 flutes
- AlTiN coating offers increased wear and heat resistance
- Solid carbide
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TC63912 |
| Cutter Diameter (Inch) | 0.1875" (3/16) |
| Length of Cut (Inch) | 0.7500" (3/4) |
| Shank Diameter (Inch) | 0.1875" (3/16) |
| Corner Radius (Inch) | 0.0100" |
| Overall Length (Inch) | 2.0000" (2) |
| Coating | ALTIN |
| Substrate | Carbide |
| Number of Flutes | 5 |
| Product Type | Corner Radius End Mill |
