These fully stocked solid carbide Titan USA Reamers feature a 45 Degree chamfer angle and straight flutes, ideal for through and blind hole applications.
Features:
- Straight flute general purpose reamers for through and blind hole applications
- 45 Degree chamfer angle
- Solid carbide
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TC87424 |
| Shank Diameter | 0.3490" |
| Overall Length (Inch) | 3.5000" (3-1/2) |
| Overall Reach (Inch) | 2.1250" (2-1/8) |
| Margin Length (Inch) | 1.2500" (1-1/4) |
| Number of Flutes | 6 |
| Coating | Uncoated |
| Substrate | Carbide |
| Product Type | Chucking Reamer |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Titan USA
Reamer Diameter (Inch):
15/43"
Reamer Diameter (Decimal Inch):
0.3490"
Reamer Diameter (mm):
8.86mm
Flute Length (Inch):
1-1/4"
Flute Length (Decimal Inch):
1.2500"
Flute Length (mm):
31.75mm
Number of Flutes:
6
Material:
Carbide
Finish/Coating:
Uncoated
interval quantity:
1
