Features:
- 2 flutes
- Solid carbide
- AlTiN coating offers increased wear and heat resistance
- Flat tip (non-cutting) design for increased strength in chamfering and profiling applications
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TC87693 |
| Cutter Diameter (Inch) | 0.5000" (1/2) |
| Shank Diameter (Inch) | 0.5000" (1/2) |
| Length of Cut (Inch) | 0.2100" |
| Overall Length (Inch) | 3.0000" (3) |
| Tip (Inch) | 0.0800" |
| Theoretical Tip Length (Inch) | 0.0400" |
| Number of Flutes | 2 |
| Included Angle (Degree) | 90 Degree |
| Angle per Side (Degree) | 45 Degree |
| Coating | AlTiN |
| Substrate | Carbide |
| Product Type | Chamfer Mill |
