Screw-on boring bars, for position 80 degree rhombic insert with 7 degree clearance.
| # MFG | 6845543 |
| Connection Diameter Machine Side (Inch) | 1" |
| Functional Length (Inch) | 10" |
| Functional Width (Inch) | 0.687" |
| Head Length (Inch) | 1-3/4" |
| Minimum Bore Diameter (Inch) | 1-1/4" |
| Shank Height (Inch) | 0.975" |
| Body Material | Carbide |
| Application | For 80 Degree Rhombic Insert, For Miniature Machining |
| Tool Type | Internal Indexable-Turn Tool |
| Rake Angle Axial (Degree) | 0 Degree |
| Rake Angle Radial (Degree) | -4 Degree |
