Tungaloy 6846542 | SWGT13T3AFPR-MJ NS740 0.547" Diameter x 0.157" Thickness x 0.059" Radius Cermet Milling Insert

$21.78 $18.08
(You save $3.70)
Brand:
Tungaloy
Material:
Carbide
Manufacturer's Grade:
NS740
Width (Inch):
35/64"
Width (Decimal Inch):
0.5470"
Width (mm):
13.89mm
Inscribed Circle (Inch):
35/64"
Inscribed Circle (Decimal Inch):
0.5470"
Inscribed Circle (mm):
13.89mm
Thickness (Inch):
5/32"
Thickness (Decimal Inch):
0.1570"
Thickness (mm):
3.99mm
SKU:
23024144
UPC:
Weight:
1.23 LBS
Shipping:
Calculated at Checkout

For finishing, precision machining with ground insert.


Product Specifications
Manufacturer Part Number6846542
Corner Radius (Inch)0.059"
Depth of Cut Maximum (Inch)0.157"
Inscribed Circle Diameter (Inch)0.547"
Insert Thickness (Inch)0.157"
Insert Width (Inch)0.547"
Maximum Feed per Tooth0.0079"/tooth
Minimum Feed per Tooth0.002"/tooth
Number of Cutting Edges4
Wiper Edge Length0.079"
ApplicationFace Milling
Body MaterialCarbide
GradeNS740
Cutting Edge MaterialCermet
Applicable MaterialSteel, Stainless Steel
