Product Specifications
| EDP Number | 1552 |
| Diameter (Decimal Inch) | 0.0300" |
| Diameter (Inch) | 1/32" |
| Diameter (mm) | 0.79mm |
| Shank Diameter (Decimal Inch) | 0.1250" |
| Shank Diameter (Inch) | 1/8" |
| Shank Diameter (mm) | 3.18mm |
| Length of Cut (Decimal Inch) | 0.0781" |
| Length of Cut (Inch) | 5/64" |
| Length of Cut (mm) | 1.98mm |
| Overall Length (Decimal Inch) | 1.5000" |
| Overall-Length-(Inch) | 1-1/2" |
| Overall Length (mm) | 38.10mm |
| Helix Angle (Degree) | 30 Degree |
| Number of Flutes | 2 |
| Cutting Direction | Right |
| Application | P |
| Shank Style | Plain |
| Series | E5020 |
| Coating | Bright |
| Material | Carbide |
| Cut Type | Center |
| End Type | Single End |
| Product Type | Square End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Mill Diameter (Inch):
1/32"
Mill Diameter (Decimal Inch):
0.0300"
Mill Diameter (mm):
0.79mm
Number of Flutes:
2
Length of Cut (Inch):
5/64"
Length of Cut (Decimal Inch):
0.0781"
Length of Cut (mm):
1.98mm
Material:
Carbide
Finish/Coating:
Bright
Shank Diameter (Inch):
1/8"
Shank Diameter (Decimal Inch):
0.1250"
Shank Diameter (mm):
3.18mm
Application:
P
Single or Double End:
Single
Overall Length (Inch):
1-1/2"
Overall Length (Decimal Inch):
1.5000"
Overall Length (mm):
38.10mm
Helix Angle:
30 Degree
