YG1 BH134B | BT40 Taper 0.078" - 0.787" Range x 1.960" Diameter x 4.000" Gage Length x 1.575" Minimum Functional Length x 3.555" Maximum Functional Length ER32 ER Collet Chuck

$179.53 $147.21
(You save $32.32)
Brand:
YG1
Collet Series:
ER25
interval quantity:
1
SKU:
55008217
UPC:
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
YG1 BH134B | BT40 Taper 0.078" - 0.787" Range x 1.960" Diameter x 4.000" Gage Length x 1.575" Minimum Functional Length x 3.555" Maximum Functional Length ER32 ER Collet Chuck

Product Specifications
Manufacturer Part NumberBH134B
Taper TypeBT40
Clamping range0.078" - 0.787"
Body Diameter (Decimal Inch)1.960"
Body Diameter (mm)49.78mm
Gage Length (Decimal Inch)4.000"
Gage Length (mm)101.60mm
Minimum Functional Length (Decimal Inch)1.575"
Maximum Functional Length (Decimal Inch)3.555"
StyleStandard
Taper AccuracyAT3
G Value6.3
RPM15000
Coolant SystemAD/B
Collet SeriesER32
Product TypeER Collet Chuck
