Product Specifications
| Diameter (Decimal Inch) | BK956 |
| Diameter (Decimal Inch) | 1.5000" |
| Diameter (mm) | 38.10mm |
| Overall Length (Decimal Inch) | 7.8740" |
| Overall Length (mm) | 200.00mm |
| Thread Length (Decimal Inch) | 1.260" |
| Thread Length (mm) | 32.00mm |
| Square Length (Decimal Inch) | 1.1300" |
| Square Length (mm) | 28.70mm |
| Shank Diameter (Decimal Inch) | 1.2330" |
| Shank Diameter (mm) | 31.30mm |
| Square Size (Decimal Inch) | 0.9250" |
| Square Size (mm) | 23.5mm |
| Neck Diameter (Decimal Inch) | 0.0610" |
| Neck Diameter (mm) | 30.81mm |
| Number of Flutes | 4 |
| Size & Pitch | 1-1/2-8" |
| Tap Type | SPFL |
| Size | 1-1/2" |
| Pitch | 8 TPI |
| Thread Series | UN |
| Pitch Limit | H6 |
| Chamfer Type | Modified Bottoming |
| Chamfer Length | 2P-3P |
| Finish | Hardslick |
| Material | Super HSS |
| Blank Standard | DIN/ANSI |
| Helix Angle | 40 Degree |
| Length/Diameter | 2.5XD |
| Useable Length (Decimal Inch) | 3.9370" |
| Useable Length (mm) | 100.00mm |
| Product Type | Spiral Flute Tap |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Thread Size (Inch):
1.5000"
Thread Size (mm):
38.10mm
Number of Flutes:
4
Chamfer:
Modified Bottoming
Material:
Super HSS
Finish/Coating:
Hardslick
Overall Length (Inch):
7.8740"
Overall Length (mm):
200.00mm
