Product Specifications
| Manufacturer Part Number | D1211110 |
| Diameter (Inch) | 1-5/32" |
| Diameter (Decimal Inch) | 1.1563" |
| Diameter (mm) | 29.37mm |
| Flute Length (Inch) | 7-1/4" |
| Flute Length (Decimal Inch) | 7.2500" |
| Flute Length (mm) | 184.15mm |
| Overall Length (Inch) | 12-7/8" |
| Overall Length (Decimal Inch) | 12.8750" |
| Overall Length (mm) | 327.03mm |
| Point Length (Decimal Inch) | 0.3474" |
| Point Length (mm) | 8.82mm |
| Number of Flutes | 2 |
| Morse Taper | 4 |
| Point Angle | 118 Degree |
| Helix Angle | 33 Degree |
| Coolant Through | No |
| Blank Standard | ANSI |
| Coating | Oxide |
| Material | HSS |
| Hole Tolerance | h8 |
| Application | P |
| Cutting Direction | Right |
| Series | D1211 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Drill Bit Size (Inch):
1-5/32"
Drill Bit Size (Decimal Inch):
1.1563"
Drill Bit Size (mm):
29.37mm
Shank Type:
Morse Taper
Drill Point Angle:
118 Degree
Flute Length (Inch):
7-1/4"
Flute Length (Decimal Inch):
7.2500"
Flute Length (mm):
184.15mm
Material:
HSS
Coating:
Oxide
interval quantity:
1
