| Manufacturer Part Number | DGE433009F |
| Diameter (Inch) | 9/64" |
| Diameter (Decimal Inch) | 0.1406" |
| Diameter (mm) | 3.57mm |
| Shank Diameter (Inch) | 13/55" |
| Shank Diameter (Decimal Inch) | 0.2362" |
| Shank Diameter (mm) | 6.00mm |
| Flute Length (Inch) | 1-4/39" |
| Flute Length (Decimal Inch) | 1.1024" |
| Flute Length (mm) | 28.00mm |
| Overall Length (Inch) | 2-3/5" |
| Overall Length (Decimal Inch) | 2.5984" |
| Overall Length (mm) | 66.00mm |
| Point Length (Decimal Inch) | 0.0422" |
| Point Length (mm) | 1.07mm |
| Number of Flute | 2 |
| Cutting Direction | Right Hand |
| Point Angle (Degree) | 118 Degree |
| Helix Angle (Degree) | 30 Degree |
| Shank Tolerance | h6 |
| Coolant Pressure | 20 Bar |
| Blank Standard | DIN6537 |
| Hole Tolerance | m7 |
| Material | Carbide |
| Coating | DLC |
| Product Type | Coolant Fed Drill |
