| Manufacturer Part Number | DGE433186 |
| Diameter (Inch) | 52/71" |
| Diameter (Decimal Inch) | 0.7323" |
| Diameter (mm) | 18.60mm |
| Shank Diameter (Inch) | 37/47" |
| Shank Diameter (Decimal Inch) | 0.7874" |
| Shank Diameter (mm) | 20.00mm |
| Flute Length (Inch) | 3-83/85" |
| Flute Length (Decimal Inch) | 3.9764" |
| Flute Length (mm) | 101.00mm |
| Overall Length (Inch) | 6-2/85" |
| Overall Length (Decimal Inch) | 6.0236" |
| Overall Length (mm) | 153.00mm |
| Point Length (Decimal Inch) | 0.2200" |
| Point Length (mm) | 5.59mm |
| Number of Flute | 2 |
| Cutting Direction | Right Hand |
| Point Angle (Degree) | 118 Degree |
| Helix Angle (Degree) | 30 Degree |
| Shank Tolerance | h6 |
| Coolant Pressure | 20 Bar |
| Blank Standard | DIN6537 |
| Hole Tolerance | m7 |
| Material | Carbide |
| Coating | DLC |
| Product Type | Coolant Fed Drill |
