| Manufacturer Part Number | DPP447147 |
| Diameter (Inch) | 11/19" |
| Diameter (Decimal Inch) | 0.5787" |
| Diameter (mm) | 14.70mm |
| Shank Diameter (Inch) | 17/27" |
| Shank Diameter (Decimal Inch) | 0.6299" |
| Shank Diameter (mm) | 16.00mm |
| Flute Length (Inch) | 2-15/34" |
| Flute Length (Decimal Inch) | 2.4409" |
| Flute Length (mm) | 62.00mm |
| Overall Length (Inch) | 4-2/15" |
| Overall Length (Decimal Inch) | 4.1339" |
| Overall Length (mm) | 105.00mm |
| Number of Flutes | 2 |
| Point Angle | 180 Degree |
| Helix Angle | 20 Degree |
| Length/Diameter | 2 |
| Series | DPP447 |
| Shank Tolerance | h6 |
| Coolant Through | No |
| Coating | X-Coated |
| Material | Carbide |
| Hole Tolerance | h7 |
| Application | P,K |
| Cutting Direction | Right |
