Product Specifications
| Manufacturer Part Number | EI880120 |
| Diameter (Inch) | 43/91" |
| Diameter (Decimal Inch) | 0.4724" |
| Diameter (mm) | 12.00mm |
| Shank Diameter (Inch) | 43/91" |
| Shank Diameter (Decimal Inch) | 0.4724" |
| Shank Diameter (mm) | 12.00mm |
| Length of Cut (Inch) | 17/24" |
| Length of Cut (Decimal Inch) | 0.7087" |
| Length of Cut (mm) | 18.00mm |
| Overall Length (Inch) | 3-25/46" |
| Overall Length (Decimal Inch) | 3.5433" |
| Overall Length (mm) | 90.00mm |
| Ball Nose Radius (Inch) | 13/55" |
| Ball Nose Radius (Decimal Inch) | 0.2362" |
| Ball Nose Radius (mm) | 6.00mm |
| Neck Diameter (Decimal Inch) | 0.4488" |
| Neck Diameter (Inch) | 22/49" |
| Neck Diameter (mm) | 11.40mm |
| LBS (Inch) | 1-5/12" |
| LBS (mm) | 36.00mm |
| Number of Flute | 2 |
| Helix Angle (Degree) | 30 Degree |
| Cutting Direction | Right Hand |
| Shank Style | Plain |
| Material | Carbide |
| Coating | Diamond |
| Product Type | Ball Nose End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Mill Diameter (Inch):
43/91"
Mill Diameter (Decimal Inch):
0.4724"
Mill Diameter (mm):
12.00mm
Number of Flutes:
2
Length of Cut (Inch):
17/24"
Length of Cut (Decimal Inch):
0.7087"
Length of Cut (mm):
18.00mm
Material:
Carbide
Overall Length (Decimal Inch):
3.5433"
Overall Length (Inch):
3-25/46"
Overall Length (mm):
90.00mm
Shank Diameter (Inch):
43/91"
Shank Diameter (Decimal Inch):
0.4724"
Shank Diameter (mm):
12.00mm
Finish/Coating:
Diamond
Cutting Direction:
Right Hand
Helix Angle (Degree):
30 Degree
