Product Specifications
| EDP Number | EM814060 |
| Diameter (Decimal Inch) | 0.2400" |
| Diameter (Inch) | 13/55" |
| Diameter (mm) | 6.00mm |
| Shank Diameter (Decimal Inch) | 0.2362" |
| Chamfer Size (Decimal Inch) | 0.0100" |
| Shank Diameter (Inch) | 13/55" |
| Shank Diameter (mm) | 6.00mm |
| Length of Cut (Decimal Inch) | 0.6299" |
| Length of Cut (Inch) | 17/27" |
| Length of Cut (mm) | 16.00mm |
| Overall Length (Decimal Inch) | 2.2441" |
| Overall Length (mm) | 57.00mm |
| Overall Length (Inch) | 2-21/86" |
| Number of Flutes | 3 |
| Chamfer Size (mm) | 0.38mm |
| Series | EM814 |
| Helix Angle (Degree) | 20 Degree |
| Shank Style | Plain |
| Coating | ALTiN |
| Cut Type | Center Cut |
| Length Type | Long |
| Material | Carbide |
| Cutting Direction | Right |
| Application | P |
| Produce Type | Roughing End Mill |
