Product Specifications
| Manufacturer Part Number | EMD47026 |
| Diameter (Inch) | 13/32" |
| Diameter (Decimal Inch) | 0.4063" |
| Diameter (mm) | 10.32mm |
| Shank Diameter (Inch) | 7/16" |
| Shank Diameter (Decimal Inch) | 0.4375" |
| Shank Diameter (mm) | 11.11mm |
| Length of Cut (Inch) | 15/16" |
| Length of Cut (Decimal Inch) | 0.9375" |
| Length of Cut (mm) | 23.81mm |
| Overall Length (Inch) | 2-3/4" |
| Overall Length (Decimal Inch) | 2.7500" |
| Overall Length (mm) | 69.85mm |
| Chamfer Size (Inch) | 1/143" |
| Chamfer Size (Decimal Inch) | 0.0070" |
| Chamfer Size (mm) | 0.18mm |
| Number of Flutes | 4 |
| Series | EMD47 |
| Shank Style | Flat |
| Helix Angle | Multiple |
| Coating | AlTiN |
| Material | Carbide |
| Cut Type | Center |
| Type | High Performance |
| Application | P,M,K |
| Cutting Direction | Right |
