Product Specifications
| Manufacturer Part Number | EMD49036 |
| Diameter (Inch) | 9/16" |
| Diameter (Decimal Inch) | 0.5625" |
| Diameter (mm) | 14.29mm |
| Shank Diameter (Inch) | 9/16" |
| Shank Diameter (Decimal Inch) | 0.5625" |
| Shank Diameter (mm) | 14.29mm |
| Length of Cut (Inch) | 1-1/8" |
| Length of Cut (Decimal Inch) | 1.1250" |
| Length of Cut (mm) | 28.58mm |
| Overall Length (Inch) | 3-1/2" |
| Overall Length (Decimal Inch) | 3.5000" |
| Overall Length (mm) | 88.90mm |
| Corner Radius (Inch) | 1/40" |
| Corner Radius (Decimal Inch) | 0.0250" |
| Corner Radius (mm) | 0.64mm |
| Number of Flutes | 4 |
| Series | EMD49 |
| Shank Style | Flat |
| Helix Angle | Multiple |
| Coating | AlTiN |
| Material | Carbide |
| Cut Type | Center |
| Type | High Performance |
| Application | P,M,K |
| Cutting Direction | Right |
