Product Specifications
| # Manufacturer Number | G8A47911 |
| Diameter (Decimal Inch) | 0.3937" |
| Diameter (Inch) | 37/94" |
| Diameter (mm) | 10.00mm |
| Shank Diameter (Decimal Inch) | 0.3937" |
| Shank Diameter (Inch) | 37/94" |
| Shank Diameter (mm) | 10.00mm |
| Length of Cut (Decimal Inch) | 0.4331" |
| Length of Cut (Inch) | 13/30" |
| Length of Cut (mm) | 11.00mm |
| Overall Length (Decimal Inch) | 2.7559" |
| Overall-Length-(Inch) | 2-65/86" |
| Overall Length (mm) | 70.00mm |
| Corner Radius (Decimal Inch) | 0.0197" |
| Corner Radius (Inch) | 1/51" |
| Corner Radius (mm) | 0.50mm |
| LBS (Decimal Inch) | 1.2598" |
| LBS-(Inch) | 1-20/77" |
| LBS (mm) | 32.00mm |
| Neck (Decimal Inch) | 0.3819" |
| Neck (Inch) | 21/55" |
| Neck (mm) | 9.70mm |
| Helix Angle (Degree) | 4 Degree |
| Number of Flute | 4 |
| Coating | Blue |
| Material | Carbide |
| Cut Type | Center Cutting |
| Cutting Direction | Right |
| Shank Style | Plain |
| Product Type | Corner Radius End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Mill Diameter (Inch):
37/94"
Mill Diameter (Decimal Inch):
0.3937"
Mill Diameter (mm):
10.00mm
Number of Flutes:
4
Corner Radius (Inch):
1/51"
Corner Radius (Decimal Inch):
0.0197"
Corner Radius (mm):
0.50mm
Length of Cut (Inch):
13/30"
Length of Cut (Decimal Inch):
0.4331"
Length of Cut (mm):
11.00mm
Shank Type:
Plain
Material:
Carbide
Finish/Coating:
Blue
Shank Diameter (Inch):
37/94"
Shank Diameter (Decimal Inch):
0.3937"
Shank Diameter (mm):
10.00mm
Application:
P,H
Overall Length (Inch):
2 65/86"
Overall Length (Decimal Inch):
2.7559"
Overall Length (mm):
70.00mm
Cutting Direction:
Right
