Product Specifications
| EDP Number | G92924 |
| Diameter (Decimal Inch) | 0.3750" |
| Diameter (Inch) | 3/8" |
| Diameter (mm) | 9.53mm |
| Shank Diameter (Decimal Inch) | 0.3750" |
| Shank Diameter (Inch) | 3/8" |
| Shank Diameter (mm) | 9.53mm |
| Length of Cut (Decimal Inch) | 0.8750" |
| Length of Cut (Inch) | 7/8" |
| Length of Cut (mm) | 22.23mm |
| Overall Length (Decimal Inch) | 2.5000" |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (mm) | 63.50mm |
| Corner Radius (Decimal Inch) | 0.0200" |
| Corner Radius (mm) | 0.51mm |
| Number of Flutes | 4 |
| Series | G929 |
| Shank Style | Flat |
| Helix Angle | Multi Helix |
| Coating | Y Coated |
| Material | Carbide |
| Cut Type | Center |
| Corner Type | Corner Radius |
| Type | Roughing Corner Radius End Mill |
| Application | P,K |
| Cutting Direction | Right Hand |
| Product Type | Roughing End Mill |
