Product Specifications
| Manufacturer Part Number | G9I02028N |
| Mill Diameter (Inch) | 7/16" |
| Mill Diameter (Decimal Inch) | 0.4375" |
| Mill Diameter (mm) | 11.11mm |
| Shank Diameter (Inch) | 7/16" |
| Shank Diameter (Decimal Inch) | 0.4375" |
| Shank Diameter (mm) | 11.11mm |
| Length of Cut (Inch) | 1" |
| Length of Cut (Decimal Inch) | 1.0000" |
| Length of Cut (mm) | 25.40mm |
| Overall Length (Inch) | 2-3/4" |
| Overall Length (Decimal Inch) | 2.7500" |
| Overall Length (mm) | 69.85mm |
| Ball Nose (Decimal Inch) | 0.2188" |
| Ball Nose (Inch) | 7/32" |
| Ball Nose (mm) | 5.56mm |
| Helix | 30 Degree |
| Series | G9I02 |
| Coated | X-Coating |
| Material | Carbide |
| Type | Ball Nose Single End |
| Corner Type | Ball Nose |
