Product Specifications
| Manufacturer Part Number | G9I03200N |
| Mill Diameter (Inch) | 37/47" |
| Mill Diameter (Decimal Inch) | 0.7874" |
| Mill Diameter (mm) | 20.00mm |
| Shank Diameter (Inch) | 37/47" |
| Shank Diameter (Decimal Inch) | 0.7874" |
| Shank Diameter (mm) | 20.00mm |
| Length of Cut (Inch) | 1-1/2" |
| Length of Cut (Decimal Inch) | 1.4961" |
| Length of Cut (mm) | 38.00mm |
| Overall Length (Inch) | 4-1/64" |
| Overall Length (Decimal Inch) | 4.0157" |
| Overall Length (mm) | 102.00mm |
| Ball Nose (Decimal Inch) | 0.3543" |
| Ball Nose (Inch) | 45/127" |
| Ball Nose (mm) | 9.00mm |
| Helix | 30 Degree |
| Series | G9I03 |
| Coated | X-Coating |
| Material | Carbide |
| Type | Ball Nose Single End |
| Corner Type | Ball Nose |
