Product Specifications
| Manufacturer Part Number | GMF61080 |
| Diameter (Inch) | 23/73" |
| Diameter (Decimal Inch) | 0.3150" |
| Diameter (mm) | 8.00mm |
| Shank Diameter (Inch) | 23/73" |
| Shank Diameter (Decimal Inch) | 0.3150" |
| Shank Diameter (mm) | 8.00mm |
| Length of Cut (Inch) | 43/91" |
| Length of Cut (Decimal Inch) | 0.4724" |
| Length of Cut (mm) | 12.00mm |
| Overall Length (Inch) | 2-12/25" |
| Overall Length (Decimal Inch) | 2.4803" |
| Overall Length (mm) | 63.00mm |
| Number of Flutes | 4 |
| Helix Angle | Variable |
| Series | GMF61 |
| Shank Style | Flat |
| Coating | Y-Coated |
| Material | Carbide |
| Cut Type | Center |
| Cutting Direction | Right |
| Length Type | Extended Length |
| Application | P, M, K, S |
