Product Specifications
| Manufacturer Part Number | GMF63902 |
| Diameter (Inch) | 2/17" |
| Diameter (Decimal Inch) | 0.1181" |
| Diameter (mm) | 3.00mm |
| Shank Diameter (Inch) | 13/55" |
| Shank Diameter (Decimal Inch) | 0.2362" |
| Shank Diameter (mm) | 6.00mm |
| Length of Cut (Inch) | 8/29" |
| Length of Cut (Decimal Inch) | 0.2756" |
| Length of Cut (mm) | 7.00mm |
| Overall Length (Inch) | 2-21/86" |
| Overall Length (Decimal Inch) | 2.2441" |
| Overall Length (mm) | 57.00mm |
| Corner Radius (Inch) | 1/85" |
| Corner Radius (Decimal Inch) | 0.0118" |
| Corner Radius (mm) | 0.30mm |
| Number of Flutes | 4 |
| Helix Angle | Variable |
| Series | GMF63 |
| Shank Style | Flat |
| Coating | Y-Coated |
| Material | Carbide |
| Cut Type | Center |
| Cutting Direction | Right |
| Length Type | Extended Length |
| Application | P, M, K, S |
