Product Specifications
| Manufacturer Part Number | GMG13250 |
| Diameter (Inch) | 62/63" |
| Diameter (Decimal Inch) | 0.9843" |
| Diameter (mm) | 25.00mm |
| Shank Diameter (Inch) | 62/63" |
| Shank Diameter (Decimal Inch) | 0.9843" |
| Shank Diameter (mm) | 25.00mm |
| Length of Cut (Inch) | 1-52/71" |
| Length of Cut (Decimal Inch) | 1.7323" |
| Length of Cut (mm) | 44.00mm |
| Overall Length (Inch) | 4-5/53" |
| Overall Length (Decimal Inch) | 4.0945" |
| Overall Length (mm) | 104.00mm |
| Number of Flutes | 6 |
| Helix Angle | Variable |
| Series | GMG13 |
| Shank Style | Flat |
| Coating | Y-Coated |
| Material | Carbide |
| Cut Type | Center |
| Cutting Direction | Right |
| Length Type | Standard Length |
| Application | P, M, S |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Mill Diameter (Inch):
62/63"
Mill Diameter (Decimal Inch):
0.9843"
Mill Diameter (mm):
25.00mm
Number of Flutes:
6
Length of Cut (Inch):
1-52/71"
Length of Cut (Decimal Inch):
1.7323"
Length of Cut (mm):
44.00mm
Shank Type:
Flat
Material:
Carbide
Finish/Coating:
Y-Coated
Shank Diameter (Inch):
62/63"
Shank Diameter (Decimal Inch):
0.9843"
Shank Diameter (mm):
25.00mm
Application:
P, M, S
Overall Length (Inch):
4-5/53"
Overall Length (Decimal Inch):
4.0945"
Overall Length (mm):
104.00mm
Helix Angle:
Variable
Cutting Direction:
Right
