Product Specifications
| EDP Number | T6217707 |
| Size & Pitch | M20x2.5 |
| Diameter (Decimal Inch) | 0.7874" |
| Diameter (mm) | 20.00mm |
| Overall Length (Decimal Inch) | 4.4700" |
| Length/Diameter | 3.0 x D |
| Coolant Through | No |
| Overall Length (mm) | 113.54mm |
| Thread Length (Decimal Inch) | 2.0000" |
| Thread Length (mm) | 50.80mm |
| Square Length (Decimal Inch) | 0.6900" |
| Square Length (mm) | 17.53mm |
| Shank Diameter (Decimal Inch) | 0.6520" |
| Shank Diameter (mm) | 16.56mm |
| Square Size (Decimal Inch) | 0.4890" |
| Square Size (mm) | 12.42mm |
| Drill Size (Decimal Inch) | 0.6979" |
| Drill Size (mm) | 17.73mm |
| Useable Length (mm) | 50.80mm |
| Useable Length (Decimal Inch) | 2.0000" |
| Connection (Decimal Inch) | 0.652 x 0.489" |
| Connection (mm) | 16.56 x 12.42mm |
| Series | T6217 |
| Chamfer Type | Plug |
| Chamfer Length | 4P-5P |
| Thread Series | M |
| Pitch Limit | D7 |
| Blank Standard | 302 |
| Helix Angle (Degree) | 0 Degree |
| Finish | Oxide |
| Shank Type | Square |
| Trade Name | YG Tap GP |
| Tap Type | SPPT |
| Number of Flute | 3 |
| Material | HSS |
| Product Type | Spiral Point Tap |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Number of Flutes:
3
Chamfer:
4P-5P
Finish/Coating:
Oxide
Material:
HSS
Through Coolant:
No
interval quantity:
1
