Product Specifications
| Diameter (Decimal Inch) | T7405368 |
| Diameter (Decimal Inch) | 9.7870" |
| Diameter (mm) | 248.59mm |
| Overall Length (Decimal Inch) | 2.9400" |
| Overall Length (mm) | 74.68mm |
| Thread Length (Decimal Inch) | 0.5120" |
| Thread Length (mm) | 13.00" |
| Square Length (Decimal Inch) | 0.5120" |
| Square Length (mm) | 13.00" |
| Shank Diameter (Decimal Inch) | 0.3810" |
| Shank Diameter (mm) | 9.68mm |
| Square Size (Decimal Inch) | 0.2860" |
| Square Size (mm) | 7.26mm |
| Drill Size (Decimal Inch) | 0.3307" |
| Drill Size (mm) | 8.40mm |
| Useable Length (Decimal Inch) | 1.2500" |
| Useable Length (mm) | 31.75mm |
| Length/Diameter | 2.0xD |
| Coolant Through | No |
| Tap Type | STFL |
| Number Of Flutes | 3 |
| Size | M8 |
| Pitch | 1.25 TPI |
| Thread Series | M |
| Pitch Limit | D3 |
| Chamfer Type | Bottoming |
| Chamfer Length | 1.5P-2P |
| Finish | Bright |
| Material | HSS |
| Blank Standard | 322A |
| Product Type | Hand STI Tap |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Thread Size (Inch):
9.7870"
Thread Size (mm):
248.59mm
Threads Per Inch:
1.25 TPI
Thread Length (Inch):
0.5120"
Thread Length (mm):
13.00"
Overall Length (Inch):
2.9400"
Overall Length (mm):
74.68mm
Number of Flutes:
3
Material:
HSS
