| Manufacturer Part Number | T7405367 |
| Thread Size | M8 |
| Thread Size (Decimal Inch) | 0.315" |
| Thread Size (mm) | 8.00mm |
| Pitch (mm) | 1.25mm |
| Thread Series | M |
| Pitch Limit | D3 |
| Chamfer Type | Plug |
| Chamfer Length | 4P-5P |
| Overall Length (Decimal Inch) | 2.940" |
| Overall Length (mm) | 74.68mm |
| Thread Length (Decimal Inch) | 1.252" |
| Thread Length (mm) | 31.80mm |
| Square Length (Decimal Inch) | 0.440" |
| Square Length (mm) | 11.18mm |
| Shank Diameter (Decimal Inch) | 0.381" |
| Shank Diameter (mm) | 9.68mm |
| Square Size (Decimal Inch) | 0.286" |
| Square Size (mm) | 7.26mm |
| Drill Size (Decimal Inch) | 0.331" |
| Drill Size (mm) | 8.40mm |
| Connection Size (Decimal Inch) | 0.381" x 0.286" |
| Connection Size (mm) | 9.68 x 7.26mm |
| Usable Length (Decimal Inch) | 1.250" |
| Usable Length (mm) | 31.75mm |
| Length / Diameter | 2.0 x D |
| Number of Flutes | 3 |
| Coating | Bright |
| Material | HSS |
| Blank Standard | 322A |
| Series | T7405 |
| Product Type | Hand STI Tap |
