| Manufacturer Part Number | T7406483 |
| Thread Size (Inch) | 3/8" |
| Thread Size (Decimal Inch) | 0.375" |
| Thread Size (mm) | 9.53mm |
| Threads per Inch (TPI) | 16 |
| Thread Series | UNC |
| Pitch Limit | H3 |
| Chamfer Type | Bottoming |
| Chamfer Length | 1.5P-2P |
| Overall Length (Decimal Inch) | 3.380" |
| Overall Length (mm) | 85.85mm |
| Thread Length (Decimal Inch) | 0.630" |
| Thread Length (mm) | 16.00mm |
| Square Length (Decimal Inch) | 0.440" |
| Square Length (mm) | 11.18mm |
| Shank Diameter (Decimal Inch) | 0.367" |
| Shank Diameter (mm) | 9.32mm |
| Square Size (Decimal Inch) | 0.275" |
| Square Size (mm) | 6.99mm |
| Neck Diameter (Decimal Inch) | 0.354" |
| Neck Diameter (mm) | 8.99mm |
| Drill Size (Decimal Inch) | 0.395" |
| Drill Size (mm) | 10.04mm |
| Connection Size (Decimal Inch) | 0.367" x 0.275" |
| Connection Size (mm) | 9.32 x 6.99mm |
| Usable Length (Decimal Inch) | 1.660" |
| Usable Length (mm) | 42.16mm |
| Length / Diameter | 2.5 x D |
| Number of Flutes | 3 |
| Helix Angle (Degree) | 50 Degree |
| Coating | Bright |
| Material | HSS |
| Blank Standard | 322 |
| Series | T7406 |
| Product Type | Screw Thread Insert |
