Product Specifications
Diameter (Decimal Inch) | T7426528 |
Diameter (Decimal Inch) | 0.5333" |
Diameter (mm) | 13.55mm |
Overall Length (Decimal Inch) | 3.5900" |
Overall Length (mm) | 91.19mm |
Thread Length (Decimal Inch) | 1.6600" |
Thread Length (mm) | 42.16" |
Square Length (Decimal Inch) | 1.6600" |
Square Length (mm) | 42.16" |
Shank Diameter (Decimal Inch) | 0.4290" |
Shank Diameter (mm) | 10.90mm |
Square Size (Decimal Inch) | 0.3220" |
Square Size (mm) | 8.18mm |
Drill Size (Decimal Inch) | 0.4528" |
Drill Size (mm) | 11.50mm |
Useable Length (Decimal Inch) | 1.6600" |
Useable Length (mm) | 42.16mm |
Length/Diameter | 2.0xD |
Coolant Through | No |
Tap Type | STFL |
Number Of Flutes | 4 |
Size | 7/16 |
Pitch | 14 TPI |
Thread Series | UNC |
Pitch Limit | H3 |
Chamfer Type | Bottoming |
Chamfer Length | 1.5-2P |
Finish | Bright |
Material | HSS |
Blank Standard | 322 |
Product Type | Spiral Flute Tap |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Thread Size (Inch):
0.5333"
Thread Size (mm):
13.55mm
Number of Flutes:
4
Chamfer:
Bottoming
Material:
HSS
Finish/Coating:
Bright
Through Coolant:
No
