YG1 TCA283S | #8-32 Size 0.1640" Diameter x 0.1680" Shank x 2.1300" OAL 3 Flute Oxide Coated HSS-EX Spiral Flute Bottom Tap

$18.40
Brand:
YG1
Number of Flutes:
3
Chamfer:
2P - 3P
Material:
HSS-EX
Finish/Coating:
Oxide
Through Coolant:
No
Overall Length (Inch):
2-1/8"
Overall Length (Decimal Inch):
2.1300"
Overall Length (mm):
54.10mm
SKU:
15012895
Weight:
0.01 LBS
Shipping:
Calculated at Checkout

Product Specifications
EDP NumberTCA283S
Size & Pitch#8-32
Diameter (Decimal Inch)0.1640"
Diameter (mm)4.17mm
Overall Length (Decimal Inch)2.1300"
Length/Diameter2.5xD
Chamfer TypeModified Bottoming
Overall Length (mm)54.10mm
Thread Length (Decimal Inch)0.2760"
Thread Length (mm)7.01mm
Square Length (Decimal Inch)0.2500"
Square Length (mm)6.35mm
Shank Diameter (Decimal Inch)0.1680"
Shank Diameter (mm)4.27mm
Square Size (Decimal Inch)0.1310"
Square Size (mm)3.33mm
Neck Diameter (Decimal Inch)0.1200"
Connection (mm)4.27 x 3.33mm
Connection (Decimal Inch)0.168 x 0.131"
Useable Length (Decimal Inch)0.7520"
Neck Diameter (mm)3.05mm
Drill Size (Decimal Inch)0.1356"
Drill Size (mm)3.44mm
Useable Length (mm)19.10mm
Thread SeriesUNC
Pitch LimitH3
Chamfer Length2P-3P
FinishOxide
Blank Standard302A
Helix Angle (Degree)45 Degree
Number of Flutes3
Tap TypeSPFL
Shank TypeSquare
Coolant ThroughNo
Ring ColorGreen
Trade NameCombo Tap INOX
SeriesTCA-S
MaterialHSS-EX
Product TypeSpiral Flute Bottom Tap
