Product Specifications
| EDP Number | WL026HMC |
| Shoulder Diameter (Inch) | 1-3/4" |
| Shoulder Diameter (mm) | 44.5mm |
| Shoulder Diameter (Decimal Inch) | 1.752" |
| Bore Diameter (Inch) | 1/2" |
| Bore Diameter (mm) | 12.7mm |
| Nose Diameter (mm) | 26.01mm |
| Bore Diameter (Decimal Inch) | 0.5" |
| Nose Diameter (Inch) | 1" |
| Nose Diameter (Decimal Inch) | 1.024" |
| Gage Length (Decimal Inch) | 5.906" |
| Gage Length (Inch) | 5-7/8" |
| Gage Length (mm) | 150.01mm |
| Bore Depth (Decimal Inch) | 3.937" |
| Bore Depth (Inch) | 3-15/16" |
| Bore Depth (mm) | 99.9998 |
| Maximum Tool Depth inch (l2) | 1.457" |
| Maximum Tool Depth fraction (l2) | 1-7/16" |
| Maximum Tool Depth metric (L2) | 37.01mm |
| Grade | M10x1.0 |
| Taper Accuracy | AT3 |
| Grade Value | 2.5 |
| RPM | 25000 |
| Run Out (at 3D) | <0.00012" |
| Coolant system | AD/B |
| Taper # | CAT50 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
