Pyramids are compatible with 96mm RockLock top tooling. Top tooling can be mounted in vertical or horizontal orientation. Machine make and model required when ordering to ensure correct fitment. Quantity 3 RL96A-56 are included.
Features:
- PY30RL96-56 pyramids are designed to be compatible with 96mm RockLock top tooling, providing versatility in your machining setup.
- Top tooling can be mounted in both vertical and horizontal orientations, enhancing your flexibility.
- When ordering, please specify your machine make and model to ensure correct fitment.
- This set includes three RL96A-56 pyramids to support your machining needs.
| Manufacturer Part Number | PY30RL96-56 |
| Size (mm) | 158.00 x 126.00 x 30.00mm |
| Crate Dimensions (Inch) | 18" x 18" x 8" |
| Material | Aluminum |
| Product Type | RockLock Pyramid |
Overview
Time = Money
Reduce setup times by 80-95%.
Swap Vises & Fixtures Quickly.
A standard mounting pattern allows for easy movement of vises, fixtures, and tooling from machine to machine no setup time.
High Accuracy
Patented free float design ensures equal force on all 4 pull studs guaranteeing repeatability of less than .0003? (8 microns)
Standardize Your Setups.
Stop building custom adapters and subplates for every new job that comes into the shop.
Job changeover becomes simple and repeatable with the RockLock system, saving you time and money.
Simplify Programming.
Established work offsets help speed up programming time when adjusting for different jobs and top tooling.
Easy Integration.
Pull studs are easily integrated into existing fixtures and subplates. Standard 52mm and 96mm spacing allow for compatability with competitive systems.
