Product Specifications
| Min Bore Diameter (Decimal Inch) | 0.3600" |
| Hand Direction | Right Hand |
| Finish/Coating | AlTiN |
| Max Bore Depth (Decimal Inch) | 1.600" |
| Projection (Decimal Inch) | 0.0500" |
| Shank Diameter (Inch) | 3/8" |
| Shank Diameter (Decimal Inch) | 0.3750" |
| Centerline Offset (Decimal Inch) | 0.1725" |
| Offset (Decimal Inch) | 0.155" |
| Corner Radius (Decimal Inch) | 0.006" |
| Face Dimension (Decimal Inch) | 0.189" |
| Length from Holder (Decimal Inch) | 1.853" |
| Neck Diameter (Decimal Inch) | 0.3100" |
| Overall Length (Inch) | 3" |
| Overall Length (Decimal Inch) | 3.00" |
| Split Length (Decimal Inch) | 0.220" |
| Tooth Width (Decimal Inch) | 0.1420" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Minimum Bore Diameter (Decimal Inch):
0.3600"
Maximum Bore Depth (Decimal Inch):
1.600"
Material:
Carbide
Shank Diameter (Inch):
3/8"
Shank Diameter (Decimal Inch):
0.3750"
Overall Length (Inch):
3"
Overall Length (Decimal Inch):
3.00"
Finish/Coating:
AlTiN
Boring Tool Type:
Top Rake Chipbreaker
Ships:
From Partner Facility
IsDiscontinued:
